| Phase | Three Phase |
|---|---|
| Machine Type | IGBT MODULE |
| Input Voltage (Vin) | AC 415 V+/- 15% |
| Output Range | 35 AMP – 160 AMP |
| No Load Voltage | 320 |
| Rated Duty Cycle | 100% |
| Insulation Class | F |
| IP Class | IP21 |
| Cutting Thickness | UPTO 50 MM |
| Air Pressure (HP) | 4.5 – 5.5 |
| Arcing Way | HF Pilot |
